跟骨前突骨折

作者:大江 | 时间:2022-12-27 00:00:21 | 阅读:354| 显示全部楼层
介绍
创伤

患者资料
年龄:80岁
性别:男

脚/脚踝
X_RAY

跟骨前突骨折

跟骨前突骨折

Frontal

跟骨前突骨折

跟骨前突骨折

Oblique

跟骨前突骨折

跟骨前突骨折

Lateral

无移位的前跟骨突骨折。

脚踝/脚
CT

跟骨前突骨折

跟骨前突骨折

Axial bone window

跟骨前突骨折

跟骨前突骨折

Coronal bone window

跟骨前突骨折

跟骨前突骨折

Sagittal bone window

跟骨骨折前突无移位。 距骨体前外侧产生的额外撕脱型骨折。

案例讨论
该病例描述了跟骨骨折的无移位前突。 这种骨折被描述为撕脱型骨折,当过度内翻和跖屈力施加到足的分叉韧带时发生。

参考资料:
Ouellette H, Salamipour H, Thomas B, Kassarjian A, Torriani M. Incidence and MR Imaging Features of Fractures of the Anterior Process of Calcaneus in a Consecutive Patient Population with Ankle and Foot Symptoms. Skeletal Radiol. 2006;35(11):833-7. doi:10.1007/s00256-006-0154-9 - Pubmed
Yu S & Yu J. Calcaneal Avulsion Fractures: An Often Forgotten Diagnosis. AJR Am J Roentgenol. 2015;205(5):1061-7. doi:10.2214/ajr.14.14190 - Pubmed
Daftary A, Haims A, Baumgaertner M. Fractures of the Calcaneus: A Review with Emphasis on CT. Radiographics. 2005;25(5):1215-26. doi:10.1148/rg.255045713 - Pubmed
